360-Degree Passive Situational Awareness

ESM-360 System

Features

No Threat Undetected

Wide signal compatibility, including pulsed, CW and FMCW waveforms

Automatic Search Mode for hands-off, autonomous signal operations

On-board emitter processing and reporting for rapid situational awareness

Turnkey integration with tactical datalinks and mission systems

Modular, platform-ready design suitable for UAVs, pods, business jets, USVs, ground shelters and maritime platforms

Map-based graphical user interface

Pre-mission planning, in-mission operation and post-mission analysis tools

360°

Instantaneous DF Coverage

TRL 9

Operationally Proven

MISSION APPLICATIONS

High-Performance ESM

The ESM-360 supports missions across small airborne assets, maritime platforms, surface vehicles, remote sites and autonomous systems via two system variants. The ESM-360A system provides 0.5 to 40 GHz coverage for airborne platforms and the ESM-360G system is used for ground mobile, ground fixed site and small maritime vessels.

ESM-360 Airborne

Frequency Coverage of 0.5 to 40 GHz

Uses four Single Element Antenna Assemblies (SEAA) arranged to provide 360-degree instantaneous azimuth coverage

Designed for remote control operation, providing situational awareness data over line-of-sight (LOS) and beyond-line-of-sight (BLOS) datalinks

Operates with the AE-4500 ESM system, providing additional detection and direction-finding coverage to the nose and tail sectors

Two ESM systems provide data over a narrowband datalink to a common, map-based graphical user interface, delivering real-time situational awareness

spec sheets

ESM-360 Ground

Frequency Coverage of 2 to 18 GHz

Uses one Quadrature Antenna Assembly (QAA) to provide 360-degree instantaneous azimuth coverage

Enables radio frequency (RF) situational awareness of threat radars

Installed on antenna masts, mobile shelter systems, buildings and other areas of high elevation around the world

spec sheets

360° OF RF AWARENESS. ZERO BLIND SPOTS.

Advantages

Next-Generation Evolution

Future enhancements build on the AE-4500’s proven architecture to deliver high sensitivity, expanded signal coverage, deeper automation and seamless integration into multi-domain sensing suites.
